Products Description
Product Description:
Hand operated pallet truck pallet jack high quality for transport goods.
Hand pallet jack which is combined with small volume hydraulic device, handle, fork,and wheels.Used for moving mechanical equipment by human power, Internal relief valve to provide overload protection, to avoid overload use, reduce maintenance costs.
It is widely used in logistics , warehouse, factories, hospitals, schools, shopping malls, airports, sports venues, station airports and so on.
Instruction: carrying fork into the tray hole, to drive the hydraulic system to achieve the pallet cargo lifting and falling, and by the human power to complete the transfer operation. It is the easiest, most effective and most common handling and handling tool for pallet conveyors.
Products Parameters
|
Model |
RVB-2 |
RVB-2.5 |
RVB-3 |
RVB-5 |
|
Capacity(kg) |
2000 |
2500 |
3000 |
5000 |
|
Min.fork height(mm) |
75 |
|||
|
Max.fork height(mm) |
195 |
|||
|
Max.lifting height(mm) |
>=110 |
|||
|
Width overall forth(mm) |
550 |
685 |
||
|
Fork length(mm) |
1200 |
|||
|
Fork size(mm) |
150*55 |
160*60 |
||
|
Loading wheel(mm) |
80*70 |
|||
|
Steering Wheel(mm) |
180*50 |
|||
|
Net weight(kg) |
68 |
73 |
80 |
130 |
Products Details
Hand Pallet Truck Features:
Safety designed loop handle, includes neutral position, and fingertip release.
1. Spring-o-matic handle self returns.
2. 215° pivot action maneuvers in compact area.
3. One piece formed steel "C" channel tapered, reinforced forks.
4. Leak-proof pump assures maintenance-free service.
* Hard chrome-plated ram and piston.
* Urethane seals and wipers.
* Large Steer wheels with "Ball Thrust" steering.
* Sealed ball bearings throughout.
* Bearings at all pivot points can be lubricated easily.
* Tapered fork ends and nylon rollers permit easy entry and exit of pallets.
* Nylon or Polyurethane wheels and load rollers available.
* Only 1 snap ring and 4 pins to remove the hydraulic unit.
* Painted quality safety color after anti-rust treatment.
Products Application
Shipping & Packaging
